LX型電動單梁懸掛起重機

?LX型電動單梁懸掛起重機依據JB/T2603標準所設計、制造；大車運行在工字鋼軌道上，本產品適用于制造、裝配車間及倉庫等場所．但不適用于在易燃、易爆、腐蝕性介質環境中使用，也不得吊運熔融金屬。
本系列產品起重量為0.5～5t．跨度一般為3～16m，工作級別為A3～A4級。

主要特點：
1.本機起升機構一般匹配CD型(單速升降)或MD型(雙速升降)鋼絲繩電動葫蘆。
2.大車運行機構一般匹配YSE軟啟動系列電機，也可匹配變頻電機進行變頻調速。
3.本產品設有地面有線按鈕把操縱或遙控操縱兩種形式。

?????LX electric underslung crane，based on JB/T2603 standard，travelling on the I-beam track, is applicable to work in manufacturing plants,assembly? workshops? and warehouses.??It is not allowed fo be used in flammable or explosive or corrosive environments and conveying molten metal is avoided, too.

Performance data
Lifting load capacity ?0.5～5t
Range of span??? 3～16m
Allowed crane classification group? A3～A4

Main Features：
1.Hoisting mechanism of the crane generally matches with CD(single-speed)or MD(two-speed)electric wire rope hoist.
2.The travelling mechanism generally matches with?YSE motors with soft-start funclion Variable frequency motors can also be applied for speed adjustment
3.This crane has two type of manipulation：ground wired button control remote control.

?
